16 Strings Factory OEM Support High Reliability IP65 Waterproof PV Solar System DC Combiner Box 16/1
Overview Product Description Description of PV combiner box Detailed Photos Details of PV combiner box Advantage of PV c;
Basic Info
Application Range | Solar Power System |
Shell Material | Stainless Steel |
Shell Protection Grade | IP56 |
Brand | Sunway Power |
Transport Package | Carton Box, Wooden Case |
Specification | 16/1 |
Trademark | sunway power |
Origin | China |
HS Code | 9032899090 |
Production Capacity | 500000 Piece Per Year |
Product Description
Product Description
Description of PV combiner box
Name | SW-PV16/1 | |
System maximum dc voltage | 1000 | 1000 |
Maximum input current for each string | 15A | |
Maximum input strings | 16 | |
Maximum output switch current | 50A/63A | |
Number of inverter MPPT | 1 | |
Number of Output strings | 1 | |
Category of test | ‖ grade protection | |
Nominal discharge current | 20ka | |
Maximum discharge current | 40ka | |
Voltage protection level | 2.8kv | 3.8kv |
Maximum continuous operating voltage Uc | 630V | 1050A |
Poles | 2P | 3P |
Structure characteristic | Plug-push module | |
Protection grade | IP65 | |
Output switch | DC isolation switch(standard)/DC circuit | |
DC MC4/DC FUSE/DC Surge Protector | Standard | |
Monitoring module/Preventing diode | Optional | |
Installation method | Wall mounting type | |
Operating Temperature | -25ºC--+55ºC | |
Elevation of temperature | 2km | |
Permissible relative humidity | 0-95%, no condensation |
Details of PV combiner box
Advantage of PV combiner box
♦High reliabilityWith DC FUSEWith DC Surge Protection DeviceWith DC circuit breaker or DC load isolation switch.♦Strong adaptabilityIP65 desigh,waterproof,anti dust and anti ularaviolet.Strict test for high and low temperature,used widely/The simple installation, the simplified system wiring, the convenient wiring.The box body is made of cold rolled steel and other metal materials.♦Flexible configurationUsed for single crystal silicon solar modules, polycrystalline silicon solar modules, thin film solar modules.
Current rating of the photovoltaic fuse, cicuit breaker, load isolation switch is modified.
Packaging & ShippingPackage of PV combiner box
Payment of PV combiner box
Payment Term | T/T | EXW | 30% T/T in advance, paid the balance before shipment |
FOB | |||
CFR(C&F) | 30% T/T in advance, paid the balance against copy of B/L | ||
CIF | |||
L/C | L/C amount above 50,000 usd, we can accept L/C at sight | ||
West Union | Amount lower than 5000usd | ||
West Union | |||
Delivery Time | 7~10days after receiving payment for one container |
